Info About: Multisaw tracked RAIMANN KR 310 M
| |
|
|
|
| | |
|
Contact Seller | |
| You must be logged in to access these Details | |
| | |
|
| | |
|
Description
| |
Multisaw tracked RAIMANN KR 310 M
- Machines in stock
- After reconditioned
- Very good technical condition.
- In cpl. trays and table system at the output sorting the material back allowance
- Machine control of the desktop mobile
- In cpl. two sets of Lulea
- Year 2002
- The machine known world-renowned brand RAIMANN
- Machine is equipped with Quickfix system that allows changing the spacing discs (below video of the work)
TECHNICAL PARAMETERS :
- Max. cutting width 310 mm
- Max. passage width 650 mm
- Minimum wood length 450 mm
- Max disc diameter - 400 mm
- Minimum disc diameter - 250 mm
- Max. cutting height 140 mm
- Feed continuously adjustable on the inverter
- Scope feed: 8- 48 m / min
- Main motor power 55 KW
- Feeding motor power of 1.5 KW
- The engine of lifting up / down 0.55 KW
- The engine of 0.55 KW lift shaft
- Centralized lubrication caterpillar
- A lateral guide material automatically adjusted
- Line Laser
- Dimensions :
* Length 2200 mm
* Width 1900mm
* Height 2000 mm
- Weight 3400 kg
|
| | |
|
Warranty & Guarantee
| |
 WARRANTY TYPE: Not Offered
 GUARANTEE TYPE: Not Offered
|
|
